Outdoor Armored fiber optic cable 4 core-Stainless Steel Armored

Tactical-Grade Protection for Harsh Environments.Ideal for Outdoor, Data Center & Indoor Cabling.

✅ Stainless Steel Armored | Crush & Rodent Proof
✅ UV Resistant
✅ -40°C to +85°C Operating Temp

Outdoor Networking|Industrial Environments

*Field Operations,Military & Space Missions: Reliable communication for critical operations.
*Emergency & Rapid Deployment: Quick setup for temporary events or disaster recovery.
*Harsh Industrial Environments: Oil & gas, mining, and heavy machinery.

Product Name: Armored Fiber Optic Cable
Cable Type: Stainless steel tube armored
Fiber Type: G652D/G657A1/G657A2/G655C,OM1,OM2,OM3,OM4,OM5
Storage Temperature: -40℃~+80℃
Connector Type: LC/ SC/ FC/ ST/ MU/ MTRJ/ MPO
Operating Temperature: -40℃~+80℃

Applications

From field operations to data centers, our cable performs.

✅ Field Operations

Rugged and reliable for tactical deployment, emergency communication, and rapid restoration.

✅Outdoor

FTTH, CCTV systems. UV resistant for long-term outdoor installation.

✅Industrial & Harsh Environments

Oil & gas, mining, heavy machinery. Withstands high vibration, crushing, and temperature extremes.

✅Data Centers & Data Centers & Server Rooms,Indoor Networking

MPO/MTP trunk cables, armored pigtails, and hybrid/composite cable solutions for high-density racks.

✅Security & Surveillance

High-speed, tamper-proof transmission for IP cameras, CCTV systems. Ideal for parking lot entry/exit systems, campus-wide surveillance, and perimeter security in industrial, outdoor, or data center environments.

✅Up to 10x Stronger:

Stainless steel armor resists crushing, rodent damage, and heavy machinery. Lower your replacement cost.

✅Built for Extremes:

Operates in -40°C to +85°C. UV and moisture resistant. Ideal for outdoor, emergency, and live broadcasting applications.

✅Signal Integrity:

The armor shields against EMI/RFI interference, ensuring reliable data transmission.

✅Certified Quality:

Manufactured under ISO9001, RoHS, UL-compliant Trusted by clients in 15+ countries.

Designed for Extreme Conditions:

Parameter	Specification
Cable Type	Outdoor Armored Fiber Optic Cable 4 Core
Cable Count	4 Core
Fiber Type	Single-Mode(OS2): 9/125 µm
	Multi-Mode: 50/125 µm or 62.5/125 µm(OM1/OM2/OM3/OM4/OM5)
Cable Diameter	Φ4.5 ± 0.2 mm，6.0 ± 0.25 mm
Jacket Material	TPU, RoHS-Compliant
Armor Type	Stainless Steel armor
Tensile Strength	≥ 800 N (Short-Term)
	≥ 600 N (Long-Term)
Crush Resistance	≥ 3000 N/10 cm
Bending Radius	Dynamic: 20x Cable Diamete
	Static: 10x Cable Diameter
Operating Temperature	-40°C to +85°C
Storage Temperature	-40°C to +85°C
TPU Jacket	Rodentproof,UV-Proof
Attenuation	Single-Mode:1310 nm @ 1550 nm
	Multi-Mode: @ 850 nm @ 1300 nm
Bandwidth	Multi-Mode: ≥ 200 MHz·km @ 850
	≥ 500 MHz·km @ 1300 nm
Connector Options	LC, SC, ST, FC, MTP/MPO (Customizable)
Cable Weight	28kg/km

Suitable for Both Outdoor and Indoor (Data Center, Server Room, Enterprise Network) Installations.

Why Choose HHD Armored Fiber Cable？

Crush & Rodent Proof：Stainless steel armor protects your network from heavy machinery, foot traffic, and rodent damage — reducing cable replacement cost.
Flexible & Easy to Install：Tight-buffered design with 4 individual cores. Easy to strip and terminate in tight spaces or field deployments.
Built for Outdoors：UV resistant, waterproof, and operates from -40°C to +85°C. Rated for direct burial, aerial, or duct installation.

Reliable Signal：Low attenuation and high bandwidth ensure stable data transmission for critical missions — from data centers to field operations.

Indoor & Data Center Ready

Flexible, LSZH-rated, and easy to route in raised floors, cable trays, and tight spaces. Ideal for indoor and data center deployments.

See How Our Armored Cable Is Built

How to cut and strip armored fiber optic cable

Ready to order?
Request a quote via sales@hhdfiber.com — we reply within 24 hours.

Chat with us on WhatsApp：0086 15994748729
Scan the QR code to talk to our sales team directly. We typically respond within a few hours.

Related Product for Data Center

Looking for an armored fiber cable for indoor & data center use?
Check out our 12 24 48 Core LSZH Indoor Armored Cable → [Learn More]
