OM4 12 Core Mini Armored Fiber Optic Cable 4.2mm 1000m Length

Explore our high-performance OM4 12-core Mini Armored Fiber Optic Cable, featuring a durable 4.2mm construction for optimal protection and flexibility. With a length of 1000 meters, this cable is perfect for both indoor and outdoor installations, ensuring reliable data transmission at high speeds. Ideal for data centers, commercial buildings, and telecommunication networks, the OM4 fiber optic cable meets all your connectivity needs.

Application

*Optical Patch Cords
*Interconnects in Optical Communication Equipment Rooms
*Distribution Frames, and FTTX Networks
8Optical Device Termination & Integration,
*Indoor Horizontal/Vertical Cabling,
*LAN Infrastructure, and Multi-Medium Networks,
*Date centers.
*Building Cabling

Technical Features

*Metal Tube Protection
Reinforced stainless steel metal tubing safeguards high-speed network infrastructure against physical damage.
*Animal Damage Resistance
Engineered to prevent rodent/animal biting and chewing, ensuring reliable outdoor/indoor deployment.
*Superior Mechanical & Environmental Performance
High tensile stress and anti-pressure.Soft, bend-insensitive structureCompliant with harsh environments
Customizable Functionality
Tailored solutions to meet diverse customer requirements (e.g., armor type, jacket materials).
Universal Connector Compatibility,Supports all major connector types: FC, ST, LC, MPO MTP, etc.
High-Density Cabling Capability

Specification

Parameter	Specification
Cable Type	OM4 bare fiber
Cable Count	12 Core
Fiber Type	Single-Mode(OS2): 9/125 µm
	Multi-Mode: 50/125 µm or 62.5/125 µm(OM1/OM2/OM3/OM4/OM5)
Cable Diameter	Φ4.2± 0.2mm
Jacket Material	LSZH, RoHS-Compliant
Armor Type	Stainless Steel armor
Tensile Strength	≥ 400 N (Short-Term)
	≥ 200 N (Long-Term)
Crush Resistance	≥ 3500 N/10 cm
Bending Radius	Dynamic: 20x Cable Diamete
	Static: 10x Cable Diameter
Operating Temperature	-40°C to +85°C
Storage Temperature	-40°C to +85°C
Inner cable	PVC/LSZH 2.0mm fiber cable
Attenuation	Single-Mode:1310 nm @ 1550 nm
	Multi-Mode: @ 850 nm @ 1300 nm
Bandwidth	Multi-Mode: ≥ 200 MHz·km @ 850
	≥ 500 MHz·km @ 1300 nm
Connector Options	LC, SC, ST, FC (Customizable)，MTP,MPT
Cable Weight	13kgs/km

What is armored fiber optic cable?

How to cut armored fiber optic cable

Why choose armored fiber optic cable

Need Help Choosing the Right  Armored fiber optic cable?

If you're unsure which Armored fiber optic cable best fits your needs, our team is here to help. Whether you require standard single mode options or a customized solution, reach out to us at sales@hhdfiber.com for expert guidance. We can walk you through available specifications and connector options—like LC, SC, ST, or FC—and help tailor a patch cord to match your exact requirements. Same-day shipping may be available for many configurations, so you’ll have the perfect cable for your project when you need it.

Custom Options Available for 3-15days Shipment

Alongside our standard Armored fiber optic cable, we provide a tailored custom Armored fiber optic cable service. Choose from a wide range of connector types—including LC, SC, ST, and FC—as well as various cable lengths and fiber specifications. and can  ship within 3-7days to meet your urgent project needs.

If you’re unsure about the best configuration for your application, reach out to our team for guidance—our expertise ensures you get exactly what you need, exactly when you need it.
